Item Description
Applicable cable and
maximum transmission
distance
Multimode ber (with modal bandwidth of 160
MHz*km and diameter of 62.5 μm): 0.026 km
Multimode ber (OM1): 0.033 km
Multimode ber (with modal bandwidth of 400
MHz*km and diameter of 50 μm): 0.066 km
Multimode ber (OM2): 0.082 km
Multimode
ber (OM3): 0.3 km
Multimode ber (OM4): 0.4 km
Transmit power (dBm) -7.3 to -1.0
Maximum receiver
sensitivity (dBm)
-11.1
Overload power (dBm) -1.0
Extinction ratio (dB) 3.0
Operating temperature 0°C to 70°C (32°F to 158°F)
Part number 02318169
9.6.3 SFP-10G-iLR
Table 9-32 Technical
specications
Item Description
Transceiver form factor SFP+
Transmission speed 10GE
Center wavelength
(nm)
1310
Standards compliance 10GBASE-iLR (non-standard)
Connector type LC
Applicable cable and
maximum transmission
distance
Single-mode ber: 1.4 km
Transmit power (dBm) -8.2 to +0.5
Maximum receiver
sensitivity (dBm)
-14.4
Overload power (dBm) 0.5
S1700 Managed Series Ethernet Switches
Product Description
9 Optical Modules
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 218
