Item Description
Applicable cable and
maximum transmission
distance
Multimode ber (50 μm or 62.5 μm diameter): 2 km
Transmit power (dBm) -19.0 to -14.0
Maximum receiver
sensitivity (dBm)
-30.0
Overload power (dBm) -14.0
Extinction ratio (dB) 10
Operating temperature 0°C to 70°C (32°F to 158°F)
Part number 02315233
9.1.2 eSFP-FE-LX-SM1310
Table 9-2 Technical specications
Item Description
Transceiver form factor eSFP
Transmission speed FE
Center wavelength
(nm)
1310
Standards compliance Non-standard
Connector type LC
Applicable cable and
maximum transmission
distance
Single-mode ber: 15 km
Transmit power (dBm) -15.0 to -8.0
Maximum receiver
sensitivity (dBm)
-28.0
Overload power (dBm) -8.0
Extinction ratio (dB) 8.2
Operating temperature 0°C to 70°C (32°F to 158°F)
Part number 02315205
S1700 Managed Series Ethernet Switches
Product Description
9 Optical Modules
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 197
