BIDI optical modules must be used in pairs. For example, SFP-FE-LX-SM1310-BIDI must be
used with SFP-FE-LX-SM1550-BIDI.
9.1.6 SFP-FE-LX-SM1550-BIDI (Single-Fiber-Bidirectional
Module)
Table 9-6 Technical
specications
Item Description
Transceiver form factor eSFP
Transmission speed FE
Center wavelength
(nm)
Rx: 1310/Tx: 1550
Standards compliance 100BASE-BX
Connector type LC
Applicable cable and
maximum transmission
distance
Single-mode ber: 15 km
Transmit power (dBm) -15.0 to -8.0
Maximum receiver
sensitivity (dBm)
-32.0
Overload power (dBm) -8.0
Extinction ratio (dB) 8.5
Operating temperature 0°C to 70°C (32°F to 158°F)
Part number 02315202
BIDI optical modules must be used in pairs. For example, SFP-FE-LX-SM1550-BIDI must be
used with SFP-FE-LX-SM1310-BIDI.
9.2 GE eSFP Optical Modules
9.2.1 eSFP-GE-SX-MM850
S1700 Managed Series Ethernet Switches
Product Description
9 Optical Modules
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 200
