Item Description
Relative humidity 10% to 90%, noncondensing
Operating
altitude
0-2000 m (0-6562 ft.)
Certication ● EMC certication
● Safety certication
● Manufacturing certication
Part number 98010458
Optical Modules
The optical modules supported by S1700-28GFR-4P-AC are the same as those
supported by S1700-28FR-2T2P-AC. For details, see the optical modules supported
by S1700-28FR-2T2P-AC.
5.1.4 S1700-52GFR-4P-AC
Appearance
Figure 5-6 shows the appearance of an S1700-52GFR-4P-AC.
Figure 5-6 Appearance of an S1700-52GFR-4P-AC
S1700-52GFR-4P-AC
RESET
PWR
RUN
~100-240V;50/60Hz;1.2A
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
49
50
51
52
49 50 51
52
123
4 5
1 Forty-eight 10/100/1000BASE-T
ports
2 Four 1000BASE-X ports
S1700 Managed Series Ethernet Switches
Product Description
5 Hardware Structure
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 29
