Huawei S1720-10GW2P User Manual

Table 5-17 Description of service port indicators in dierent modes (one indicator
for each port)
Display
Mode
Color Status Description
Status - O The port is not connected or has been
shut down.
Green Steady on A link has been established on the port.
Green Blinking The port is sending or receiving data.
Speed - O The port is not connected or has been
shut down.
Green Steady on The port is operating at 10/100 Mbit/s.
Green Blinking The port is operating at 1000 Mbit/s.
PoE - O The port is not providing power to a PD.
Green Steady on The port is providing power to a PD.
Yellow Steady on The PoE function is disabled on the port.
Yellow Blinking The port stops providing PoE power
because of an exception (for example, an
incompatible PD is connected to the
port).
Green
and
yellow
Blinking
green
and
yellow
alternatel
y
● The power of the PD exceeds the
maximum power or power threshold
of the port.
● The total power consumption of PDs
has reached the maximum power of
the switch.
● The manual power management
mode is used and the port is not
enabled to provide power to the PD.
Power Supply Conguration
The S1720-10GW-PWR-2P has a built-in power module and does not support
pluggable power modules. The built-in power module can provide 124 W PoE
power, which ensures full PoE power on 8 ports in compliance with 802.3af or on
4 ports in compliance with 802.3at.
Heat Dissipation
The S1720-10GW-PWR-2P has no fans and uses natural heat dissipation.
Technical
Specications
Table 5-18 lists technical specications of the S1720-10GW-PWR-2P.
S1700 Managed Series Ethernet Switches
Product Description
5 Hardware Structure
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 55
