Huawei S5700 Series Hardware Description

7 RPS socket
NOTE
l It is used with an RPS cable which is not
hot swappable.
l A PoE switch can have an RPS power
supply connected to this socket to
provide inputs for system power supply
and PoE power supply. The two inputs
are independent of each other. The RPS
power supply can also be used as a
backup of the system power supply when
it does not provide PoE power.
8 Jack for AC terminal locking latch
NOTE
The AC terminal locking latch is not
delivered with the switch.
9 AC socket
NOTE
It is used with an AC power cable.
- -
Port Description
10/100/1000BASE-T port
A 10/100/1000BASE-T Ethernet electrical port sends and receives service data at
10/100/1000 Mbit/s, and must use network cables. Table 3-141 describes the attributes of a
10/100/1000BASE-T Ethernet electrical port.
Table 3-141 Attributes of a 10/100/1000BASE-T Ethernet electrical port
Attribute
Description
Connector type RJ45
Standards
compliance
IEEE802.3, IEEE802.3u, IEEE802.3ab
Working mode 10/100/1000 Mbit/s auto-sensing
Full-duplex
Maximum
transmission
distance
100 m
1000BASE-X port
When a 1000BASE-X port uses a GE optical module, it can only transmit and receive data at
1000 Mbit/s and does not support the 100 Mbit/s transmission speed. When a 1000BASE-X
port uses a GE copper module, it can transmit and receive data at 10 Mbit/s, 100 Mbit/s, or
1000 Mbit/s. Table 3-142 describes the attributes of a 1000BASE-X Ethernet optical port.
S5700 Series Ethernet Switches
Hardware Description
3 Chassis
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
224

Huawei S5700 Series Specifications

General

Model	S5700 Series
Category	Switch
Power Supply	AC or DC
Fixed GE Ports	24/48 (depending on model)
PoE	Available on some models
Routing Protocols	RIP, OSPF, BGP, IS-IS
Management	SNMP, RMON, Web-based, CLI
Operating Temperature	0°C to 45°C
VLAN	4094
Dimensions (W x D x H)	442.0 mm x 220.0 mm x 43.6 mm
