Table 3-142 Attributes of a 1000BASE-X Ethernet optical port
Attribute Description
Connector type LC/PC
Optical port
attributes
Depend on the module used
Standards
compliance
IEEE802.3z
Working mode Full-duplex
Combo port
A combo port refers to a pair of ports consisting of an optical Ethernet port and an electrical
Ethernet port on the panel. Each combo port matches only one internal forwarding port. A
combo port can be configured as an electrical port or an optical port, but only one port can be
active at a time. When one port is active, the other port is shut down.
NOTE
By default, a combo port works in auto mode, in which the port type is determined as follows:
l If the optical port has no optical module installed and the electrical port has no network cable
connected, the port type depends on which port is connected first. If the electrical port is connected
by a network cable first, the electrical port is used for data switching. If the optical port has an
optical module installed first, the optical port is used for data switching.
l If the electrical port has a network cable connected and is in Up state, the electrical port is still
used for data switching when the optical port has an optical module installed.
l If the optical port, no matter in Up or Down state, has an optical module installed, the optical port
is still used for data switching when the electrical port has a network cable connected.
l If the optical port has an optical module installed and the electrical port has a network cable
connected, the optical port is used for data switching after the switch restarts.
You can configure a combo port as an electrical or optical port using the combo-port command.
Console port
The console port is connected to a console for on-site configuration. The port must use a
console cable. The console port is used when a switch is powered on for the first time. For
details about the attributes of a console port, see Table 3-143.
Table 3-143 Attributes of a console port
Attribute
Description
Connector type RJ45
Standards
compliance
RS-232
Working mode Duplex Universal Asynchronous Receiver/Transmitter (UART)
Baud rate 9600 bit/s, 19200 bit/s, 38400 bit/s, 57600 bit/s, or 115200 bit/s
Default value: 9600 bit/s
S5700 Series Ethernet Switches
Hardware Description
3 Chassis
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
225
