Huawei S6700 Series

Numbe
r
Indicator/
Button
Color Description
Green Indicator states and meaning in V100R006
version:
l Steady on: The system is not operating
properly or is starting.
l Slow blinking: The system is operating
properly.
l Fast blinking: The system is copying
the system software and configuration
file from a USB flash drive.
Indicator states and meaning in V200R001
and later versions:
l Fast blinking: The system is starting or
is copying the system software and
configuration file from a USB flash
drive during a USB-based upgrade.
l Slow blinking: The system is running
normally.
Yellow
l Steady on: The system is performing
self-check during startup (only
applicable to V100R006).
l Blinking: The system has been
successfully upgraded using a USB
flash drive and the switch has restarted.
You can remove the USB flash drive
from the switch.
Red
l Steady on: After registering, the system
does not operate properly, or a fan or
temperature alarm has been generated.
l Blinking: An error occurred during
USB-based upgrade and the system
failed to be upgraded after a USB flash
drive is inserted.
4 MODE: mode
indicator
- Off: The service port indicators are in the
status mode (default). In the status mode,
the service port indicator shows the port
link or activity state.
Green Steady on: The service port indicators
show the port speed. After 45 seconds, the
service port indicators automatically
restore to the status mode.
