Huawei S6700 Series

Numbe
r
Indicator/
Button
Color Description
Red Steady on: The service port indicators
show the stack ID of the switch. After 45
seconds, the service port indicators
automatically restore to the status mode.
5 Mode switch
button
-
l When you press this button once, the
mode indicator turns green and the
service port indicators show the speed
of each service port.
l When you press this button a second
time, the mode indicator turns red and
the service port indicators show the
stack status.
l When you press this button a third time,
the mode indicator turns off.
If you do not press the button within 45
seconds, the mode indicator restores to
status mode.
6
Service port
indicator
Meanings of service port indicators vary in different modes.
For details, see Table 2-5.
7 ETH indicator Green
l Off: No link is established on the port.
l Steady on: The port is connected.
l Blinking: The port is sending or
receiving data.
Table 2-5 Description of service port indicators in different modes
Display Mode Color Description
Status - Off: The port is not connected or has been
shut down.
Green Steady on: The port is connected.
Yellow Blinking: The interface is sending or
receiving data.
Speed Green and
yellow
l Off: The port is not connected or has
been shut down.
l Both steady on: The port is operating at
a speed of 1000 Mbit/s.
l Both blinking: The port is operating at
a speed of 10 Gbit/s.
