Huawei S6700 Series Hardware Description

1 Twenty-four 10GE SFP+ Ethernet
optical ports
Applicable modules and cables:
l GE optical module
l GE-CWDM optical module
l GE-DWDM optical module
l GE copper module (only work at
1000 Mbit/s)
l 10GE SFP+ optical module
(OSXD22N00 not supported)
l 10GE-CWDM optical module
l 1 m, 3 m, 5 m, 10 m SFP+ high-speed
copper cables
l 3 m, 10 m AOC cables
2
Two 40GE QSFP+ optical ports
Applicable modules and cables:
l QSFP+ optical module
l 1 m, 3 m, 5 m QSFP+ high-speed
copper cables (QSFP+ to QSFP+)
l 1 m, 3 m, 5 m QSFP+ high-speed
copper cables (QSFP+ to 4*SFP+)
NOTE
A 40GE QSFP+ optical port can be split into
four 10GE ports.
3
One ETH management port 4 One console port
NOTE
It is used with a console cable. The console
cable is not delivered with the switch and needs
to be separately purchased if needed.
5 One USB port 6 Ground screw
NOTE
It is used with a ground cable.
7 Equipment serial number (ESN) label
NOTE
You can draw it out to view the ESN and MAC
address of the switch.
8 Extended card slot
Applicable card:
l ES5D21Q04Q01
9 Fan module slot
NOTE
Applicable fan module:
FAN-060B-B fan module
10 Power module slot 2
NOTE
l 350 W DC power module
l 600 W AC power module
11 Power module slot 1
NOTE
l 350 W DC power module
l 600 W AC power module
- -
