No. Indicator Color Description
8 10GE service
port indicator
(two indicators
for each port)
NOTE
Arrowheads
show the
positions of
ports. A down
arrowhead
indicates a port at
the bottom, and
an up arrowhead
indicates a port at
the top.
Meanings of service port indicators vary in different modes.
For details, see Table 2-15.
9 40GE service
port indicator
(one indicator
for each port)
Meanings of service port indicators vary in different modes.
For details, see Table 2-16.
10 ETH port
indicator
Green
l Off: The ETH port is not connected.
l Steady on: The ETH port is connected.
l Blinking: The ETH port is sending or
receiving data.
11 USB-based
deployment
indicator
- Off:
l No USB flash drive is connected to the
switch.
l The USB port is damaged.
l The indicator is damaged.
l The USB flash drive does not have any
configuration file and cannot be used
for deployment.
l The switch has been upgraded using the
USB flash drive and is restarting.
Green
l Steady on: A USB-based deployment
has been completed.
l Blinking: The system is reading data
from a USB flash drive.
Yellow Steady on: The switch has copied all the
required files and completed the file check.
The USB flash drive can be removed from
the switch.
