Table 6-3 describes the pin assignments of an MPO-MPO fiber jumper.

Table 6-3 Pin assignments of an MPO-MPO fiber jumper

Connector Type Wire Color X1 Pin

1 Blue 1

2 Orange 2

3 Green 3

4 Brown 4

9 Gray 9

10 White 10

11 Red 11

12 Black 12

Table 6-4 lists the pin assignments of an MPO-4*DLC fiber jumper.

Table 6-4 Pin assignments of an MPO-4*DLC fiber jumper

X2 Pin Wire Color X1 Pin

1 Blue 1A

2 Orange 2A

3 Green 3A

4 Brown 4A

9 Gray 4B

10 White 3B

11 Red 2B

12 Black 1B

Fiber Pigtail

A fiber pigtail is an optical fiber that has an optical connector on one end and a length of exposed

fiber at the other end. The exposed fiber can be fused to another optical fiber. Fiber pigtails are

commonly used to connect optical fibers to optical fiber modules in fiber terminal boxes.

(Couplers and jumpers are also used.) Figure 6-11 shows the structure of a fiber pigtail.
