Huawei SDongleA-01 User Manual

NO TE
● The components in the dotted box are optional.
● The inverter model is subject to change. The model information and device appearance
in this document are for reference only.
● In the networking, the inverter where the Dongle is installed is the master inverter, and
other inverters are slave inverters. Slave inverters can communicate with the Dongle
through cascading.
● When multiple inverters are cascaded, only one Smart Dongle or SmartLogger can be
connected to the RS485 communications link.
● The Smart Power Sensor connects to the RS485-2 and RS485_2 ports, or 485B2 and
485A2 ports on the master inverter. The RS485-1 and RS485_1 ports, or 485B1 and
485A1 ports are used for inverter cascading.
Table 2-4 Device description
Device Description Service
Owner
PV module Prepared by the customer Device
supplier
Inverter Master
inverter
● SUN2000-(2KTL-5KTL)-CN or SUN2000-(2KTL-5KTL)-
L0. Software version: SUN2000L V100R001C00SPC333
or later.
● SUN2000-(2KTL-6KTL)-L1. Software version:
SUN2000L V200R001C00 or later.
● SUN2000-(3KTL-20KTL)-M0
● SUN2000-(3KTL-12KTL)-M1
● SUN2000-(8KTL-20KTL)-M2
● SUN2000-(20KTL-40KTL)-M3
● SUN2000-70KTL/75KTL-C1 (optional),
SUN2000-70KTL-INM0, SUN2000-50KTL/60KTL/65KTL-
M0, SUN2000-50KTL/SUN2000-63KTL-JPM0, or
SUN2000-50KTL-JPM1. Software version: SUN2000
V300R001C00SPC112 or later.
● SUN2000-100KTL/110KTL/125KTL-M0,
SUN2000-75KTL/100KTL-M1, or SUN2000-100KTL-
INM0.
● SUN2000-175KTL/196KTL/215KTL-H0,
SUN2000-185KTL-INH0, SUN2000-185KTL-H1.
Software version: SUN2000. HAV300R001C00SPC101
or later.
● SUN2000-125KTL-JPH0
● SUN2000-196KTL/200KTL/215KTL-H3
● SUN2000-200KTL-H2
Huawei
FusionSolar Smart PV Management System
Connection
User Manual (Inverters + SDongleA) 2 Introduction to the Solution
Issue 02 (2021-11-25) Copyright © Huawei Technologies Co., Ltd. 8

Huawei SDongleA-01 Specifications

General

Brand	Huawei
Model	SDongleA-01
Category	Inverter
Language	English
