Huawei SUN2000-40KTL-M3 Quick Guide

17
2. Create a PV plant and a plant owner.
1. Open the SUN2000 app, scan the QR code of the solar inverter or manually connect to the
WLAN hotspot to access the device commissioning screen.
2. Select installer and enter the login password.
3. Tap Log in to access the quick settings screen or solar inverter home screen.
Scenario in Which Solar Inverters Are Connected to Other
Management Systems
7.2
For details, see the FusionSolar App Quick
Guide . During the FusionSolar app upgrade,
scan the QR code to download the
corresponding quick guide according to the
downloaded app version.

Huawei SUN2000-40KTL-M3 Specifications

General

Max. Efficiency	98.7%
European Efficiency	98.4%
Max. Input Voltage	1100 V
MPPT Operating Voltage Range	200 V - 1000 V
Max. Input Current per MPPT	26 A
Number of MPPTs	4
Rated Output Power	40000 W
Rated AC Voltage	400 V
Rated AC Frequency	50 Hz / 60 Hz
Adjustable Power Factor Range	0.8 leading - 0.8 lagging
Total Harmonic Distortion (THD)	<3%
DC Reverse-Polarity Protection	Yes
AC Overcurrent Protection	Yes
DC Surge Protection	Type II
AC Surge Protection	Type II
Insulation Monitoring	Yes
Residual Current Monitoring	Yes
DC Switch	Yes
Protection Class	IP66
Operating Temperature Range	-25°C to +60°C
Relative Humidity (Operating)	0% - 100%
Cooling	Natural Convection
Max. Apparent AC Power	44000 VA
AC Voltage Range	320 V - 480 V
Operating Altitude	4000 m
Display	LED Indicators
Communication	RS485, WLAN
Weight	43 kg
Max. DC Power	60000 W
