Issue 07 (2018-05-06)
Copyright © Huawei Technologies Co., Ltd.
43
Table 5-1 Cable specifications
Cable Specifications
Copper-Core Cable
Copper-Clad
Aluminum Cable or
Aluminum Alloy
Cable
Conductor
cross-sectional area
(mm
2
)
Range
16–70
25–70
Recomm
ended
value
25
35
Cable outer diameter
supported by AC
OUTPUT 1
connector (mm)
Range
18–44

You need to prepare M8 OT terminals by yourself.
If you connect a ground cable to the ground point in the maintenance compartment, prepare an M6 OT
terminal by yourself.
Requirements for OT terminals:

If a copper cable is used, use a copper wiring terminal.

If a copper-clad aluminum cable is used, use a copper wiring terminal.

If an aluminum alloy cable is used, use a copper to aluminum adapter terminal or an
aluminum wiring terminal with a copper to aluminum adapter washer.
