Input
Technical
Specications
SUN2000-450W-P
Rated PV module
power
450 W
Maximum PV
module power
472.5 W
Maximum input
voltage
80 V
MPPT voltage
range
8–80 V
Maximum short-
circuit current
13 A
Overvoltage level II
Output
Technical
Specications
SUN2000-450W-P
Rated output power 450 W
Output voltage 4–80 V
Maximum output
current
15 A
Output bypass Yes
Shutdown output
voltage/impedance
0 V/1 kΩ (±10%)
Common Parameters
Technical
Specications
SUN2000-450W-P
Dimensions (W x H
x D)
71 mm x 138 mm x 25 mm
Net weight ≤ 550 g
DC input and
output terminals
Staubli MC4
SUN2000-(3KTL-10KTL)-M1 Series
User Manual 10 Technical Specications
Issue 17 (2024-01-12) Copyright © Huawei Technologies Co., Ltd. 116
