Huawei SUN2000-4KTL-M1 User Manual

Step 7 (Optional) Install an anti-theft lock.
NO TICE
● Prepare an anti-theft lock suitable for the lock hole diameter (Ф8 mm) by
yourself. Ensure that the lock can be installed successfully.
● Outdoor waterproof lock is recommended.
● Keep the key to the anti-theft lock properly.
Figure 4-18 Installing an anti-theft lock
----End
SUN2000-(3KTL-10KTL)-M1 Series
User Manual 4 Installation
Issue 17 (2024-01-12) Copyright © Huawei Technologies Co., Ltd. 37

Huawei SUN2000-4KTL-M1 Specifications

General

Max. efficiency	98.4%
European efficiency	97.8%
AC nominal power	4000 W
Operating temperature range	-25°C to +60°C
Max. DC Voltage	600 V
Start Voltage	200 V
Max. Short-Circuit Current per MPPT	18 A
Number of MPPT Trackers	2
Cooling	Natural Convection
Protection Degree	IP65
Output Frequency	50 Hz / 60 Hz
Nominal AC voltage	220 V / 230 V / 240 V
Max. DC Power	6000 W
Rated AC Voltage	230 V
