10
Communications Port Pin Definition
Pin
Definition
Description
Pin
Definition
Function
Description
1
485A1
-1
Used to cascade
inverters or connect
to the RS485 signal
port on the
SmartLogger
2
485A1
-2
RS485
differential
signal+
Used to cascade
inverters
or
connect to the
RS485 signal port
on the
SmartLogger
3
485B1
-1
4
485B1
-2
RS485
differential
signal
5
PE
N/A
6
PE
Shielding
ground
N/A
7
485A2
Used to connect to
an RS485 signal
port on a Smart
Power Sensor for
export limitation
8
DIN1
Dry contact
interface for
grid
scheduling
N/A
9
485B2
10
DIN2
11
N/A
N/A
12
DIN3
13
GND
Used to connect to
the rapid shutdown
DI signal port or
serve as a port for
the signal cable of
the NS protection.
14
DIN4
15
DIN5
16
GND
(Optional) Installing the Signal Cable
3.6
Not all inverter models are delivered with the signal cable connector.
When laying out the signal cable, separate it from the power cable and keep it away from
strong interference sources to avoid strong communication interference.
Ensure that the protection layer of the cable is inside the connector, surplus core wires are cut
off from the protection layer, the exposed core wire is totally inserted into the cable hole, and
that the cable is connected securely.
If the Smart Dongle is configured, you are advised to install the Smart Dongle before
connecting the signal cable.
