Optional
Component
Model Function Remarks
External charger CHG-36V15A-01B Connects the battery pack
or rack to the mains and
charges the batteries or
battery pack.
Applicable to the 1
kVA UPS with long
backup time.
CHG-72V12A-01B Applicable to the 2
kVA UPS with long
backup time.
CHG-96V10A-01B Applicable to the 3
kVA UPS with long
backup time.
High-voltage
protector
OVCD-230V16A-01B The OVCD is connected
between the mains and
the UPS input. If the
mains voltage is
abnormally high, the
OVCD actively disconnects
the L wire between the
mains input and UPS to
prevent the abnormally
high voltage from owing
into the UPS and
damaging the UPS. In
addition, the OVCD
provides extra input surge
voltage absorbing
capability and input
ltering capability.
-
UPS2000-A-(1 kVA-3 kVA)
User Manual 2 Product Overview
Issue 17 (2024-01-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 23
