UPS2000-A-(6 kVA-10 kVA)
User Manual
Copyright © Huawei Technologies Co., Ltd.
Figure 3-5 Securing a UPS
Step 3 If mounting brackets are required, secure them to the UPS using M6x12 bolts, as shown in
Figure 3-6. Figure 3-7 shows the installation positions of the mounting brackets.
Mounting brackets are optional for UPSs with standard backup time and battery boxes and are not
required for UPSs with long backup time.
