UPS2000-A-(6 kVA-10 kVA)
User Manual
Copyright © Huawei Technologies Co., Ltd.
Step 8 (This step is required only for the UPS with long backup time.) Set the charge current limit
based on actual conditions. The default value is 4.0 A for the UPS with long backup time, and
the value can range from 1.0 A to 8.0 A, the interval is 0.5 A.
Figure 5-14 Setting the charge current limit
Step 9 Start the UPS in normal mode by using one of the following methods:
On the default screen, hold down for more than 5 seconds. Release the button
when you hear a beep sound. If the UPS starts successfully, it enters normal mode, as
shown in Figure 5-15.
Figure 5-15 Battery mode
On the standby screen, hold down to enter the CTR menu. Select INV ON in the
CTR menu. If the UPS starts successfully, it enters normal mode, as shown in Figure
5-16.
Figure 5-16 Battery mode
