LED Brightness
B.FLSH
Bar Flash Enable
LED brightness can be controlled from Operator Setup. Sixteen settings are available: 1 to
16. 1 is the dimmest setting while 16 is the brightest. The factory default setting is 12.
Press
ENTER/SAVE
Press
INCREASE
DECREASE
Press
ENTER/SAVE
The display will show the current LED brightness setting.
Pressing INCREASE or DECREASE will increment or decrement the LED
brightness setting one step. The display brightness will change to show the
effect of the new setting.
To save the new LED brightness, press the ENTER/SAVE pushbutton.
Do not assume that the new setting is saved once you have cho-
sen it and the BarGraph™ defaults to normal display mode. You
must press ENTER/SAVE to store the new LED brightness setting
and make it effective.
During an overrange/underrange condition, the Bar Display may be set to flash. This function
is used to enable or disable the flashing of the Bar Display.
Press
ENTER/SAVE
Press
INCREASE
DECREASE
Press
ENTER/SAVE
The display will show OM or 0FF to indicate the current state.
Pressing INCREASE sets flashing
OM, pressing DECREASE sets flashing
0FF.
To save the new Bar Flash Enable setting, press the ENTER/SAVE pushbutton.
Do not assume that the new setting is saved once you have cho-
sen it and the BarGraph™ defaults to normal display mode. You
must press ENTER/SAVE to store the new setting and make it ef-
fective.
