4
2.1 OPERATOR SETUP PROGRAMMING
Activating Operator Setup
If Operator Setup was enabled under Supervisor Setup, pressing the red ENTER/SAVE
pushbutton and holding it for more than 3 seconds activates Operator Setup.
When operator setup is first enabled,
CNF is displayed on the digital display. This is the point
at which the user enters Operator Setup.
RUN is the point at which the user exits Operator
Setup.
Operator Setup Actions
Operator Setup allows the following functions.
Operator Setup functions are cycled through using the INCREASE and DECREASE
pushbuttons. A particular function can be programmed by pressing the ENTER/SAVE
pushbutton. Pressing the INCREASE pushbutton while RUN is displayed will go to CNF and
pressing the DECREASE pushbutton while
CNF is displayed will go to RUN.
CNF
AL1
AL2
AL3
AL4
BRIGH
B.FLSH
D.FLSH
L.TEST
RUN
Enter Operator Setup (Configure)
Enter password to access Supervisor Setup
* Adjust Alarm 1 setpoint
* Adjust Alarm 2 setpoint
* Adjust Alarm 3 setpoint
* Adjust Alarm 4 setpoint
* Set LED brightness
* Enable/Disable bar display flashing
* Enable/Disable digital display flashing
Lamp test
Leave Operator Setup (run)
Pressing ENTER/SAVE (
) pushbutton while any of the above are displayed will display the
current setting and allow it to be modified. Each of the above functions is described on the
following pages.
* Access to these functions under Operator Setup may be disabled through the
OPER func-
tion under Supervisor Setup (see Section 2.2)
Note: If no pushbuttons are pressed for approximately 30 seconds, the unit will
automatically return to run mode.
PASS
To Next Page
