13
HYS
Set Hysteresis
DELAY
Set Alarm Delay
Hysteresis may be set in 0.01% increments from 0 to 10% of Full Scale. Attempting to incre-
ment past 10% will enable latching for all alarms.
Press
ENTER/SAVE
Press
INCREASE
DECREASE
Press
ENTER/SAVE
The display will show the current hysteresis setting.
Pressing the INCREASE or DECREASE pushbutton will increase or decrease
the hysteresis setting. Hold it until the desired value is reached. The longer the
pushbutton is held, the faster the display moves to the required setting.
Incrementing past 10% will enable latching on the alarms and display LCH.
Press ENTER/SAVE to store the new setting.
The delay before alarms are activated may be set from 0 to 10000 milliseconds (0 to 10 sec-
onds) in 100 millisecond (0.100 second) steps. This provides some filtering for momentary
conditions that may exceed alarm values, but are not valid alarm conditions.
Note: This delay is in addition to the normal response time and Update Rate.
Press
ENTER/SAVE
Press
INCREASE
DECREASE
Press
ENTER/SAVE
The display will show the current delay setting.
INCREASE and DECREASE pushbuttons can be used to change the delay
setting. Hold it until the new delay value is reached. Setting will show
.000 to
10.000 seconds.
The longer the pushbutton is held, the faster the display moves to the required
value.
Press ENTER/SAVE to store the new setting.
Note: Relay latching is performed electronically. The latch state will be lost and
reset if power is interrupted.
