17
B.ZERO
Set Bar Zero
B.FULL
Set Bar Full Scale
This function will not be enabled or displayed unless barform has been set to Deviation
or Variable barform (see Barform function). The BarGraph™ zero display point may be set
to a certain display value. This is not a calibration function. It only affects the range of values
that the bar display will show. This function can be used to limit the lowest value that the
BarGraph™ will display. See Example at bottom of page.
Press
ENTER/SAVE
Press
INCREASE
DECREASE
Press
ENTER/SAVE
The display will show the current BarGraph™ zero display point.
Pressing the INCREASE or DECREASE pushbutton will increase or decrease
the zero display point.
Press ENTER/SAVE to store the new setting.
This function will not be enabled or displayed unless barform has been set to Deviation
or Variable barform (see Barform function). The BarGraph™ Full Scale display point may
be set to a display value. This is not a calibration command. It only affects the bar display. This
command and the Set Bar Zero function may be used to limit the values shown on the bar
display to a specific region of interest. See Example at bottom of page.
Press
ENTER/SAVE
Press
INCREASE
DECREASE
Press
ENTER/SAVE
The display will show the current BarGraph™ Full Scale display value.
Pressing the INCREASE or DECREASE pushbutton will increase or decrease
the Full Scale display value.
Press ENTER/SAVE to store the new setting.
Example: If the BarGraph is monitoring a process that runs from 0 to 120, but the process
never falls below 110 or rises above 115, displaying from 0 to 120 on the bar
display will force the operating region to the last 1/12 of the bar display. Set-
ting B.ZERO to 110 and B.FULL to 115 will force the entire bar to display only
the region of interest.
