Humanware SmartView Synergy - Rear Panel

Note: The Base configuration of the SmartView
Synergy does not permit the attachment of a LCD
Screen or Fixed Front Control panel. Users must
connect their own LCD screen and attach a Remote
Control panel.
1.5.2 Rear panel
1 Power connector
2 USB maintenance port
3 Remote control panel connector
4 TV OUT connector
5 VGA OUT connector
6 VGA IN connector
7
123 4 5 6
1
