Hunter ceiling fan Installation And Operating Manual

6
Hunter Fan Company 41936-01 • 11/18/05
7
41936-01 • 11/18/05 Hunter Fan Company
3 • Installing the Blade Irons
3-1. Turn the fan upside down. Use the ceiling fan package to support
the fan while assembling the blade irons.
3-2. Loosen all of the blade iron assembly screws. Do not completely
remove the screws.
3-3. Remove and discard all of the shipping blocks.
3-4. Slide the blade iron under the switch housing plate, aligning the
two notches with the two blade iron assembly screws.
3-5. To engage the blade iron fully, pull the blade forward under the
loosened blade iron assembly screws.
3-6. Securely tighten the blade iron assembly screws.
3-7. Repeat until all blade irons are assembled.
Shipping Blocks
Blade Iron
Blade Iron
Assembly
Screws
Steps 3-1 – 3-7
Two Notches
for Screws
Steps 3-4 – 3-7 DetailSteps 3-4 – 3-7 Detail
