5
B. FLOWSYNC BODY (FCT Series)
1. Flow-Sync Tee: The Tee is installed into the
irrigation system and houses the Flow-Sync
2
. Plug (replace with Flow-Sync at installation)
3. O-rings: Provides sealing of plug in
sensor body
4. Cap: Retains plug or sensor in sensor body
5. Cover: Snaps over the top of the sensor
Note: FCT Tees are ordered for the desired pipe
diameter separately from the Flow-Sync (see table
on page 8).
2
3
4
5
1
