Hunter TCX575 - Bead Press System (BPS) Components

8  1. Getting Started Operation Instructions for TCX575 Tire Changer
Bead Press System (BPS) Components
The functional parts of the BPS are:
1. Articulated Arm 6. Demounting/match mounting disc
2. Rim Presser cone 7. Sliding locking lever
3. Control Lever 8. Demounting arm lock
4. Bead presser roller 9. Arm end of travel pin
5. Match mounting lock
