22 2. Basic Procedures Operation Instructions for TCX575 Tire Changer
Lift tire and repeat this procedure for lower bead.
With the BPS bead lifter - If the lower bead becomes reseated onto the rim, the lower
bead lifter may be placed under the tire and used to lift the tire into the drop center.
Always insert a bead lever into the BPS bead lifter to position and stabilize the roller.
Raise bead lifter and rotate tire to loosen bead. Remove bead lifter.
Swing the mount/demount arm assembly up and away from the wheel.
Remove tire from rim.
2.4 Mounting Standard Tire to Rim
Always use this “checklist” as a guide when mounting tires to ensure proper service.
There are four basic steps when mounting a tire to a rim:
Position the bead on top of the mounting lip of the mount/demount head.
Position the bead under the demounting lip of the mount/demount head.
Lock the tire to the rim in the mounting position.
Slip the bead into the drop center.
These four basic steps to mounting do not necessarily follow the same sequence,
however all four steps need to be performed to mount a tire to a rim.
Mount a standard tire to rim as follows:
Lubricate inside and outside of both beads of the tire to be mounted with supplied
mounting paste.
