INSTALLATION
10
■ If a valance is included, “snap” on a valance hanger next to each “L” bracket.
■ Center the valance in relationship to the headrail and slide it into the valance hangers.
Install the Vanes
■ Determine the desired light/view direction.
■ Rotate the vane hooks so the slot between the long and
the short prong is facing you.
■ Push the vane into the hook until it “snaps” into place.
Mounting
Clip
“L” Bracket
Side
View
Wall
Valance Hanger
Valance
(Optional)
3
1
/2"
2
1
/4"
1
/2"
4
1
/4"
Vane
Finished
Side
Top View
Finished
Side
Light Diffusion
into Room
Light Diffusion
into Room
Light Source (Sun)
Light Source (Sun)
Short
Prong
Long
Prong
Carrier
