22 TECHNICAL DATA 189

Turn signal LED

Brake/tail light LED

License plate lamp LED

22.6 Tires

Front tires Rear tires

120/70 R 17 M/C 58H TL

Continental ContiAttack SM

160/60 R 17 M/C 69H TL

Continental ContiAttack SM

The tires specified represent one of the possible series production tires. Additional information is available in the Service section

under:

www.husqvarna-motorcycles.com

22.7 Fork

Fork article number 14.15.8Q.12

Fork WP Performance Systems 4860 ROTA SPLIT

Compression damping

Comfort 20 clicks

Standard 15 clicks

Sport 10 clicks

Full payload 10 clicks

Rebound damping

Comfort 20 clicks

Standard 15 clicks

Sport 10 clicks

Default Chapter5
- Table of Contents5
1 Means of Representation9
- Symbols Used9
- Formats Used10
2 Safety Advice11
- Use Definition - Intended Use11
- Misuse11
- Degrees of Risk and Symbols12
- Tampering Warning12
- Safe Operation13
- Protective Clothing14
- Work Rules14
- Environment14
- Owner's Manual15
3 Important Notes16
- Manufacturer and Implied Warranty16
- Operating and Auxiliary Substances16
- Spare Parts, Accessories16
- Service17
- Figures17
- Customer Service17
4 View of Vehicle18
- View of Vehicle, Front Left (Example)18
- View of Vehicle, Rear Right (Example)20
5 Serial Numbers22
- Chassis Number22
- Type Label22
- Key Number23
- Engine Number23
- Fork Part Number24
- Shock Absorber Article Number24
6 Controls25
- Clutch Lever25
- Hand Brake Lever25
- Throttle Grip26
- Horn Button26
- Light Switch27
- Turn Signal Switch27
- Emergency off Switch28
- Electric Starter Button28
- Ignition/Steering Lock29
- Indicator Lamps Overview29
- Opening the Filler Cap30
- Closing Filler Cap31
- Seat Unlocking32
- Grab Handles32
- Passenger Footrest33
- Shift Lever33
- Foot Brake Lever34
- Side Stand35
7 Speedometer36
- Overview36
- Activation36
- Messages on the Speedometer37
- Setting the Speedometer37
- Setting Kilometers or Miles39
- Setting the Clock40
- Setting the Service Display41
- Speed, Time, and DST Distance 142
- Speed, Time, and DST2 Distance 243
- AVG Average Speed, ART Operating Hours, and ODO Total Distance Covered44
8 Preparing for Use45
- Advice on First Use45
- Running in the Engine46
- Loading the Vehicle47
9 Riding Instructions49
- Performing Checks and Vehicle Care When Preparing for Use49
- Starting50
- Starting off52
- Shifting, Riding52
- Applying the Brakes55
- Stopping, Parking57
- Transport58
- Refueling59
10 Service Schedule62
- Additional Information62
- Required Work62
- Recommended Work65
11 Tuning the Chassis66
- Fork/Shock Absorber66
- Adjusting the Compression Damping of the Fork66
- Adjusting the Rebound Damping of the Fork67
- Compression Damping of the Shock Absorber68
- Adjusting the Low-Speed Compression Damping of the Shock Absorber68
- Adjusting the High-Speed Compression Damping of the Shock Absorber70
- Adjusting the Rebound Damping of the Shock Absorber71
- Measuring the Rear Wheel Dimension Unloaded72
- Checking the Static Sag of the Shock Absorber73
- Checking the Riding Sag of the Shock Absorber74
- Adjusting the Spring Preload of the Shock Absorber75
- Adjusting the Riding Sag77
- Handlebar Position78
- Adjusting the Handlebar Position78
12 Service Work on the Chassis80
- Raising the Motorcycle with the Rear Wheel Stand80
- Removing the Rear of the Motorcycle from the Wheel Stand80
- Raising the Motorcycle with the Front Wheel Stand81
- Taking the Motorcycle from the Front Lifting Gear82
- Cleaning the Dust Boots of the Fork Legs82
- Removing the Fork Protector84
- Installing the Fork Protector84
- Checking the Play of the Steering Head Bearing85
- Adjusting the Steering Head Bearing Play86
- Removing the Seat87
- Mounting the Seat87
- Take off the Side Cover88
- Mounting the Side Cover88
- Removing the Front Fender89
- Installing the Front Fender89
- Removing the Air Filter90
- Installing the Air Filter91
- Checking the Chain for Dirt92
- Cleaning the Chain92
- Checking the Chain Tension93
- Adjusting the Chain Tension95
- Checking the Chain, Rear Sprocket, Engine Sprocket, and Chain Guide96
- Adjusting the Chain Guide101
- Adjusting the Basic Position of the Clutch Lever102
- Checking/Correcting the Fluid Level of the Hydraulic Clutch103
13 Brake System105
- Antilock Braking System (ABS)105
- Adjusting the Basic Position of the Hand Brake Lever107
- Checking the Brake Discs107
- Checking the Front Brake Fluid Level108
- Adding Front Brake Fluid109
- Checking the Front Brake Linings111
- Checking the Free Travel of Foot Brake Lever112
- Adjusting the Basic Position of the Foot Brake Lever113
- Checking the Rear Brake Fluid Level114
- Adding Rear Brake Fluid115
- Checking the Rear Brake Linings116
14 Wheels, Tires118
- Wheels, Tires118
- Removing the Front Wheel118
- Installing the Front Wheel119
- Removing the Rear Wheel121
- Installing the Rear Wheel123
- Checking the Rear Hub Rubber Dampers125
- Checking the Tire Condition127
- Tubeless Tire System129
- Checking the Tire Air Pressure129
- Checking Spoke Tension130
15 Electrical System132
- Removing the Battery132
- Installing the Battery134
- Recharging the Battery136
- Changing the Main Fuse139
- Changing the ABS Fuses140
- Changing the Fuses of Individual Power Consumers143
- Removing the Headlight Mask with the Headlight145
- Installing the Headlight Mask with the Headlight147
- Changing the Headlight Bulb148
- Changing the Parking Light Bulb150
- Checking the Headlight Setting151
- Adjusting the Headlight Range151
16 Cooling System153
- Checking the Antifreeze and Coolant Level154
- Checking the Coolant Level156
- Draining the Coolant158
- Filling/Bleeding the Cooling System159
17 Tuning the Engine162
- Checking the Basic Position of the Shift Lever162
- Adjusting the Basic Position of the Shift Lever162
18 Service Work on the Engine164
- Changing the Fuel Screen164
- Checking the Engine Oil Level165
- Changing the Engine Oil and Oil Filter, Cleaning the Oil Screens166
- Adding Engine Oil171
19 Cleaning, Care173
- Cleaning the Motorcycle173
- Checks and Maintenance Steps for Winter Operation175
20 Storage177
- Preparing for Use after Storage179
21 Troubleshooting180
22 Technical Data183
- Engine183
- Engine Tightening Torques184
- Capacities188
- Engine Oil188
- Coolant188
- Fuel188
- Chassis189
- Electrical System190
- Tires191
- Fork191
- Shock Absorber192
- Chassis Tightening Torques193
23 Substances198
24 Auxiliary Substances201
25 Standards202
26 Index of Special Terms203
27 List of Abbreviations204
28 List of Symbols205
- Red Symbols205
- Yellow and Orange Symbols205
- Green and Blue Symbols205
- Index207
