12 SERVICE WORK ON THE CHASSIS 85
– Remove the motorcycle from the work stand.
12.10 Removing the seat
V00492-10
–
Pull on the loop
while raising the rear of the seat.
– Pull off the seat sideways at the front ends from the side cover.
– Pull seat back and lift it off.
12.11 Mounting the seat
V00497-10
–
Stretch the seat at the front ends slightly and position holding tabs
on holders
.
The holding tabs engage in the holder.
–
Press holding tab
into the bushings
.
–
Insert locking pin
into the lock housing
and push down the rear of the seat
until the locking pin engages with an audible click.
– Check, finally, that the seat is correctly mounted.
