The numbers in the figure represent:
1. Body
2. Hatch to display and keypad
3. Stop button
4. Front wheels
5. Rear wheels
6. Ultrasonic sensors
7. Headlights
8. Replaceable cover
9. Rating plate (incl. product identification
code)
10. Display
11. Keypad
12. Cutting system
13. Chassis box with electronics, battery and
motors
14. Main switch
15. Handle
16. Blade disc
17. Skid plate
18. Contact plates
19. LED for operation check of the charging
station and boundary wire
20. Charging station
21. Power supply (the appearance may differ
depending on market)
22. Cable markers
23. Measurement gauge when installing the
boundary wire (the measurement gauge is
broken loose from the box)
24. Screws for securing the charging station
25. Operator’s Manual and Quick Guide
26. Alarm decal
27. Extra blades
28. Low voltage cable
4 - Introduction 1201 - 004 - 25.03.2020
