1. PLACEMENT OF AND CONNECTING THE CHARGING STATION
See chapters 3.2 and 3.3 in the complete operator’s manual on Husqvarna’s website.
1. Place the charging station at a central position in the working area, with a lot of open space in front of the charging station and
on a relatively horizontal surface.
2. Connect the power supply’s low voltage cable to the charging station and the power supply.
3. Connect the power supply to a 100-240 V wall socket.
4. Place the robotic lawnmower in the charging station to charge the battery while the boundary wire is laid. Set the main switch
to position 1.
2. PLACEMENT OF THE BOUNDARY WIRE AND THE GUIDE WIRE
See chapters 3.5-3.7 in the complete operator’s manual on Husqvarna’s website.
1. Lay the boundary wire so that it forms a loop around the working area.
2. Make an eyelet at the point where the guide wire will later be connected.
3. Run the guide wire to the point on the boundary loop where the connection will be made. Avoid laying the wire at tight angles.
3. CONNECTING THE BOUNDARY WIRE AND THE GUIDE WIRE
See chapters 3.6 and 3.7 in the complete operator’s manual on Husqvarna’s website.
1. Narrowpassagesinthegardenmakeitdifcultfortheroboticlawnmowertondthechargingstation.Theroboticlawnmower
canbeleadtoremotegardenareasusingtheguidewire.Theguidewirealsohelpstheroboticlawnmowertoquicklyndthe
charging station.
2. Lay the guide wire under the charging station and at least 2 m / 6.5 ft straight out from the front edge of the charging station.
3. Open the connectors and lay the wire ends in the recesses on each connector.
4. Press the connectors together using a pair of pliers.
5. Cut off any surplus boundary wire. Cut 1-2 cm / 0.4-0.8 ” above the connectors.
6. Press the connectors onto the contact pins, marked AL (left) and AR (right), on the charging station. It is important that the
right-hand wire is connected to the right-hand contact pin, and the left-hand wire to the left-hand pin.
7. Fasten the connector to the contact pin marked G1 on the charging station.
4. CONNECTING THE GUIDE WIRE TO THE BOUNDARY WIRE
See chapter 3.7 in the complete operator’s manual on Husqvarna’s website.
1. Cut the boundary wire with a wire cutters at the centre of the eyelet that was made in step 2.2.
2. Connect the guide wire to the boundary wire using the accompanying couplers. Press the couplers completely together with a
polygrip.
5. STARTING AND STOPPING
See chapters 4.1, 4.2 and 4.5 in the complete operator’s manual on Husqvarna’s website.
STARTING
1. Open the cover by pressing the STOP button.
2. Set the main switch to position 1.Whenyoudothisforthersttime,astartupsequencestartswhereyouselectafourdigit
PIN code among other things.
3. Press the START button and close the cover.
STOPPING
Press the STOP button.
6. ADJUSTING THE ROBOTIC LAWNMOWER TO SUIT THE SIZE OF YOUR LAWN
See chapter 4.7 in the complete operator’s manual on Husqvarna’s website.
Themowingresultsdependonmowingtime.AdjustthemowingtimetosuityourgardenusingtheTimer function. You decide
whattimesduringthedaytheroboticlawnmoweristowork.Theroboticlawnmowermowsabout73m²/0.018acreperhour
andday(approx.68m²/0.017forAutomower315and56m²/0.014acreforAutomower
®
310). For example; if your garden
consists of
800m²/0.2acre
of lawn, the robotic lawnmower should work on average 11 hours per day (12 hours for Automower
315 and 15 hours for Automower
®
310).
7. MAINTENANCE
See chapter 5 in the complete operator’s manual on Husqvarna’s website.
1. Themainswitchshouldbeinthe0positionduringallworkontheroboticlawnmower’schassis,suchascleaningorreplacing
the blades. Replace the blades regularly for the best mowing result.
2. Never use a high-pressure washer or even running water to clean the robotic lawnmower. Never use solvents for cleaning.
3. All connections to the charging station (power supply, boundary and guide wire) must be disconnected if there is a risk of a
thunderstorm.
4. Fully charge the battery at the end of the season before winter storage.
EN
