Husqvarna Automower 415X User Manual

1.2 Product overview
6
8
9
11
16
19
17
18
15
13
7
14
24
26
25
27
28
29
30
10
20
23
22
21
12
4
3
2
5
1
1. Product body
2. Top cover
3. Hatch to display and keypad
4. STOP button
5. Rear wheels
6. Front wheels
7. Headlights
8. Blade disc
9. Skid plate
10. Contact plates
11. LED indicator for operation check of the charging
station, boundary wire and guide wire
12. Charging station
13. Display
14. Keypad
15. ON/OFF button
16. Rating plate with product identification code
17. Maintenance tool
1
18. Cutting system
19. Chassis box with electronics, battery and motors
20. Loop wire for boundary wire and guide wire
2
21. Connectors for the loop wire
3
22. Stakes
4
23. Couplers for the loop wire
5
24. Screws to attach the charging station
25. Power supply
6
26. Measurement gauge for the installation of the
boundary wire (remove the measurement gauge
from the carton of the product)
27. Operator's Manual and Quick Guide
28. Blade
29. Low-voltage cable
30. Alarm decal
1
Found below the top cover.
2
Is a part of the installation kit which is purchased separately.
3
Is a part of the installation kit which is purchased separately.
4
Is a part of the installation kit which is purchased separately.
5
Is a part of the installation kit which is purchased separately.
6
The appearance can be different for different markets.
4 - Introduction 1650 - 005 - 17.03.2022

Husqvarna Automower 415X Specifications

General

Cutting width	22 cm
Cutting height min	20 mm
Cutting height max	50 mm
Battery type	Li-Ion
Typical charging time	60 min
Maximum slope performance inside installation	40%
Maximum area capacity	1500 m²
Battery voltage	18 V
Battery capacity	2.0 Ah
Connectivity	Bluetooth, Cellular
Weather resistance	Yes
Anti-theft system	PIN code, Alarm, GPS tracking
Blade type	Pivoting razor blades
Typical mow time on one charge	60 minutes
