Wheel motor
•
Cutting motor
•
Cut height
The
Info - Motors - Wheel motor
menu shows:
•
Speed
for the left/right wheel motor.
•
Current (mA)
for the left/right wheel motor.
•
Power (%)
for the left/right wheel motor.
The
Info - Motors - Cutting motor
menu shows:
•
Speed
of the cutting motor.
•
Current (mA)
for the cutting motor.
•
Average current (mA)
for the cutting motor.
The
Info - Motors - Cut height
menu shows:
•
Cutting height
: The blade disc height setting
measured in steps.
•
Current (mA)
for the cutting height motor.
4.4.1.8 Tools - Info - GPS navigation
The
Tools - Info - GPS navigation
shows:
•
Satellites
: The number of satellites the GPS
receiver is currently in contact with.
•
Position
: The products position in longitude and
latitude.
4.4.2 Tools - History, total
4.4.2.1 Tools - History, total - Key data
The Tools - History, total - Key data
menu shows:
•
Total running
: The total time in hours that the wheel
motors have been running.
Note:
Total running
also includes the time when the
product is running without mowing.
•
Total mowing
: The total time in hours that the blade
motor has been running.
•
Total search time
: The total time in hours that the
product has been in search mode. This means the
time from starting to search for the charging station,
until the product has docked. Depending on the
installation and work area, it is normal with 10-20%
search time of the total running time.
•
Total charge time
: The total time in hours when the
product has been charging.
•
Complete chargings
: The total number of complete
chargings. A complete charging is defined as a
charging that proceeds for more than 20 minutes,
and is terminated when the charge current is less
than 300 mA.
•
Efficiency
: How much of the total operating time that
the product has mowed the lawn.
Efficiency
is the
mowing time divided by the charging time + running
time.
•
Run time/Fault
: The average time the product has
run for each fault message displayed.
Run time/fault
is the total running time divided by the number of
occurring faults.
4.4.2.2 Tools - History, total - Search times
The
History, total - Search times
menu has 2 sections:
•
Overview
: Shows the average, max and min search
time of the last 12 searches.
•
Search times
: Shows each of the last 12 searches.
4.4.2.3 Tools - History, total - Mow times
The
History, total - Mow times
menu has 2 sections:
Note: The mow time is defined as the time that the blade
motor has been running.
•
Overview
: Shows the average, max and min mow
time of the last 12 mowing operations. The menu
shows each of the last 12 mowing operations.
•
Mow times
: Shows each of the last 12 mowing
operations.
4.4.2.4 Tools - History, total - Battery capacity
The
History, total - Battery capacity
menu has 4
sections: Test 1, 2, 3 and 4. Each of the 4 most recent
battery tests are saved in
Battery capacity
. For each of
the tests the following is shown:
•
Date
: The date of the test
•
Time
: The time of the test
•
Chargings
: The number of complete chargings at
the time of the test.
•
Capacity
: Measured battery capacity (mAh) during
the test.
4.4.3 Tools - History, trip
The
History, trip - Key data
has the same information as
in
History, total - Key data
. However, in
History, trip -
Reset trip values
it is possible to reset all values, just
like for a trip meter in a car.
4.4.4 Tools - Test
Note: The battery voltage should be at least 18 V when
testing the wheel and blade motors
4.4.4.1 Tools - Test - Motors
Note: The STOP button needs to be enabled to enter
this menu. Refer to
To operate the product with the
hatch opened on page 9
.
The
Tools - Test - Motors
has 2 sections:
Wheel motor
and
Blade motor
.
•
Wheel motor
:
1. Lift the product so that the drive wheels are off
the ground.
2. Increase (Arrow up button) the power to 80%
and block each drive wheel in different positions.
Check that the motor starts again when the
blocking is released.
12 - Special menus 420/430X/430XH/
440/450X/450XH
1191 - 001 -
