The numbers in the illustration represent:
1. Body
2. LED indicator lamp of the product
3. STOP/START button
4. Ultrasonic sensors
5. Front wheels
6. Rear wheels
7. LED indicator lamp of the charging station
8. Contact strips
9. Park button
10. Charging station
11. Cutting system
12. Chassis box with electronics, battery and motors
13. Handle
14. Main switch
15. Rating plate (including product identification code)
16. Blade disc
17. Skid plate
18. Measurement gauge
19. Low voltage cable
20. Alarm decal
21. Cable markers
22. Power supply
1
23. Extra blades
24. Screws for securing the charging station
25. Operator’s manual and Quick Guide
26. Couplers for loop wire
2
1
The appearance may differ depending on market
2
Is a part of the Installation kit which is purchased separately.
4 - Introduction 1457 - 005 - 16.10.2020
