3. Make sure that the oil level in the transmission oil
tank is between the 2 horizontal lines on the tank.
4. Fill with oil if the oil level is below the lower line, but
do not fill above the top line. Refer to
Technical data
on page 51
for recommended oil.
9.2.5 To remove and install the air filter
1. Remove the air filter cover. Refer to
To remove and
install the air filter cover on page 19
.
2. Carefully remove the air filter.
3. Clean and examine the air filter.
4. Install in the opposite sequence.
9.2.6 To examine and replace a spark plug
1. Open the engine cover.
2. Remove the spark plug cap and clean around the
spark plug.
3. Remove the spark plug with a spark plug wrench.
4. Examine the spark plug. Replace it if the electrodes
are burned or if the insulation has cracks or
damages. If the spark plug is not damaged, clean it
with a steel brush.
5. Measure the electrode gap and make sure that it is
correct. Refer to
Technical data on page 51
.
6. Bend the side electrode to adjust the electrode gap.
7. Put the spark plug back in and turn it by hand until it
touches the spark plug seat.
8. Tighten the spark plug with the spark plug wrench
until the washer is compressed.
9. Tighten a used spark plug ⅛ of a turn more, and a
new spark plug ¼ turn more.
CAUTION: Spark plugs that are not
tightened correctly can cause damage to the
engine.
10. Replace the ignition cable shoe.
CAUTION: Do not try to start the engine if
the spark plug or ignition cable is removed.
28 - Repair instructions 1676 - 001 - 26.11.2021
