11 Technical data
11.1 Technical data
R 214T R 214TC
Dimensions
Length without cutting deck, mm 1942 1942
Width without cutting deck, mm 883 883
Length including cutting deck
1
, mm 2227 2227
Width including cutting deck
1
, mm 994 994
Height, mm 1131 1131
Weight without cutting deck, with empty tank, kg 207 207
Weight including cutting deck
1
, with empty tank,
kg
243 243
Wheel base, mm 887 887
Track width, front, mm 711 711
Track width, rear, mm 627 627
Tire dimensions 170/60-8 170/60-8
Tire pressure, rear – front, kPa / bar / PSI 60 / 0.6 / 8.5 60 / 0.6 / 8.5
Max. gradient, degrees ° 10 10
Engine
Brand / Model Husqvarna / HV586AE Husqvarna HV586AE
Nominal engine output, kW
2
11.3 11.3
Displacement, cm
3
586 586
Max. engine speed, rpm 2900 ± 100 2900 ± 100
Max. speed forward, km/h 9 9
Max. speed reverse, km/h 6 6
Fuel, min. octane grade 91 91
Tank volume, liters 12 12
Oil Class SF, SG, SH or SJ SAE40,
SAE30, SAE10W-30,
SAE10W-40 or SAE5W-20
Class SF, SG, SH or SJ SAE40,
SAE30, SAE10W-30,
SAE10W-40 or SAE5W-20
Oil volume incl. filter, liters 1.6 1.6
Oil volume excl. filter, liters 1.4 1.4
Start motor Electric start 12V Electric start 12V
Transmission
Brand Tuff Torq Tuff Torq
Model K46H K46H
Oil, class SF-CC SAE 10W/30 SAE 10W/30
1
Measured with cutting deck Combi 94
2
The power rating of the engine indicated is the average net output (at specified rpm) of a typical production en-
gine for the engine model measured to SAE standard J1349/ISO1585. Mass production engines may differ from
this value. Actual power output for the engine installed on the final product will depend on the operating speed,
environmental conditions and other values.
1676 - 001 - 26.11.2021 Technical data - 51
