11.2 Control points and play
Control points
Parallelism cutting deck with cutting height in position 1 ± 2 mm / ± 0.079 in
Control of cutting height in position 1 25 ± 2 mm / 0.98 ± 0.079 in
Distance between support plate and drive belt 3-6 mm /1/8 in -1/4 in
Distance belt tensioner lever arm and belt guide, disen-
gaged deck
17 ± 5 mm / 7/16 in ± 3/16 in
Play
Brake cable 1 mm / 0.040 in
Cable for the hydrostatic transmission pedals 0 mm / 0 in
11.3 Tightening torques
Tightening torques
Steering drive 5-10 Nm / 3.5-7 lb ft
Steering cable pulley 20-30 Nm / 14-21 lb ft
Belt pulley 45-50 Nm / 32-36 lb ft
Blades M10 bolt 45-50 Nm / 32-36 lb ft
Blade bearings 20-25 Nm / 14-18 lb ft
Belt tensioner 15-25 Nm / 10-18 lb ft
Engine mounting screws 20-25 Nm / 14-18 lb ft
Gearbox mounting screws 20-25 Nm / 14-18 lb ft
Engine belt pulley 70-80 Nm / 50-56 lb ft
1676 - 001 - 26.11.2021 Technical data - 53
