Hussmann CRFD - Page 18

IGFL-CRFD/CRFD 1/2-0508
18
DATE:
PROJECT TITLE:
DRAWING #:
DRAWN BY:
PRODUCTION ORDER #:
DRAWING TITLE:
DATE:
Hussmann Corporation, Int'l.
13770 Ramona Avenue
Chino, CA. 91710 (909)-590-4910 Lic.#: 644406
REVISIONS:
#: DESCRIPTION:
CHECKED BY:
BY:
FILE LOCATION:
D.QUAN
---
PAGE OF1
1
07/22/05
1
2
3
H:\WIRESCHEMATICS\NEW-WIRING
CRFD 7'-4"-BACK TO BACK
W0400012
CRFD 7'-4" FLORA REFRIGERATED CASE
CIRCUIT #1
NOTE: CASE MUST
BE GROUNDED
40.6
38.7 0.0
34.4
32.8 0.0
L1
L2
L3
208 V 240 V
LOADING
CIRCUIT #1
NOTE: CASE MUST
BE GROUNDED
40.6
38.7 0.0
34.4
32.8 0.0
L1
L2
L3
208 V 240 V
LOADING
LIGHT SWITCH
125-01-0307
CANOPY LIGHTING
(8) F32T8-48" LAMP
125-03-1073
(4) LIGHT FIXTURE
125-02-1082
FAN MOTOR (3) GE 9W - 115V
125-01-0615A
M M
TERMINAL
BLOCK
125-01-0295
FISHER™ EVAPOWAY™
DM20WW-3D
2000W @ ~ 240 VAC
125-01-0500
POWER: ~ 208 / 230 VAC - 3Ø - 50/60 HZ.
M
EVAPORATOR FAN MOTOR
FIXTURE LITHONIA
C232 125-02-1082
FIXTURE LITHONIA
C232 125-02-1082
FIXTURE LITHONIA
C232 125-02-1082
FIXTURE LITHONIA
C232 125-02-1082
FUSE 125-01-3282 15 AMP FUSE FUSE HOLDER 125-01-3283
FUSE 125-01-3282
(2) 15 AMP FUSE FUSE HOLDER (2)
125-01-3283
FUSE 125-01-8537 (3) 20 AMP FUSE
(1)FUSE HOLDER
125-01-8533
125-01-8508
NEMA L22-30P
MALE PLUG
L1 L2 L3 N G
CONDENSING UNIT
240 VAC 3 PHASE
m
225-01-1666 BECKETT PUMP 1PC13A
FUSE 125-01-3282
15 AMP FUSE
FUSE HOLDER
125-01-3283
SAFETY
SWITCH
FLOAT SWITCH
125-01-8538
SWITCH
3 POLE
WHITE-14 AWG
BLACK-14 AWG
BLACK-10 AWG
BLACK-10 AWG
YELLOW-10 AWG
RED-10 AWG
RED-10 AWG
BLACK-10 AWG
RED-10 AWG
BLACK-10 AWG
RED-10 AWG
YELLOW-10 AWG
BLACK-10 AWG
RED-10 AWG
WHITE-14 AWG
BLACK-14 AWG
Wiring Diagrams (Cont'd)
