9. Service Tips
WARNING
ALWAYS DISCONNECT THE ELECTRICAL POWER AT THE MAIN DISCONNECT WHEN SERVICING OR
REPLACING ANY ELECTRICAL COMPONENT OF THIS REFRIGERATOR. THIS INCLUDES, BUT IS NOT
LIMITED TO SUCH ITEMS AS FANS AND THERMOSTATS.
Fan Blade Replacement
The evaporator fan is located at the back of the case
directly beneath the display pan. Should the fan blade
ever need servicing. ALWAYS REPLACE THE FAN
BLADE WITH THE RAISED EMBOSSING SIDE OF
THE BLADE INSTALLED TOWARD THE MOTOR.
Honeycomb Removal & Cleaning
CAUTION: DO NOT TEAR THE HONEYCOMB
1) Remove the honeycomb assembly as follows:
Insert a small Phillips screwdriver behind the rear edge
of the honeycomb on the right hand end and gently
pull down. The bottom of the honeycomb will drop
down. Continue down the length of the case, lifting the
honeycomb out.
2) To clean honeycomb:
Mix powdered detergent, in warm water. (5 to 7
Tablespoons per gallon)
Immerse or spot clean the honeycomb. Use care not to
damage the cell structure of the honeycomb.
Rinse thoroughly in clean water. Shake excess water
from the honeycomb and dry. (if heat is used, do not
exceed 140 F dry heat)
3) Install honeycomb by inserting the notched side
up against the defl ector and press upwards inserting
the bottom of the honeycomb into the back ledge. Slide
along the honeycomb, pressing the front edge upward
into the ledge. Be careful no to damage the cells or cut
yourself on the edges of the honeycomb.
LED Driver Replacement
The Driver for the canopy LED lamps is located beneath
the canopy panel at the left hand end of the case.
For access to the LED Driver:
- Remove the screws that fasten the canopy to the
exterior top of the case
- Pull the top of the canopy forward and rotate it down to
remove it from the case
- Replace or service the LED Driver as required and
replace the canopy in reverse order of removal.
