HUSSMANN_GDF_1.1 SHEET SIZE D
MATERIAL - N/A
THIRD
ANGLE
PROJECTION
UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES.
DRAWN BY -CRAIG BOOREY
APPROVED BY - CRAIG BOOREY
TOLERANCES ARE:
DECIMALS .XX
u.03, .XXX u.010
ANGLES
u 2v
DATE DRAWN - 7-25-16
ECN-CAP-0003047
REVIEWED BY -CRAIG BOOREY
REF -
3011858
DIAGRAM-IM-03-E5-
S
REV ECN DATE REVISION DESCRIPTION REV BY CHKD BY APPR BY
A ECN-CAP-0003047 2016/07/25 RELEASED TO PRODUCTION CB CB CB
B ECN-CAP-0003963 2016/10/03 CHANGED COMPRESSOR CB CB CB
REVISION HISTORY
NOTES:
CASE MUST BE GROUNDED
WHEN PASSING WIRES THROUGH METAL HOLES A GROMMET MUST BE USED
B
SHEET 1 OF 1
CIRCUIT #1
L1
L2
LOADING
11.9
11.3
13.7
13.1
208V 240V
BUNDLE
ORANGE
LIGHT SWITCH
125-01-0307
WHT # 14
BLK # 14
SHELF
CANOPY
LED DRIVER
LIGHT CIRCUIT
0.39A 42W @ 120V
RED +
BLUE -
5' LED LIGHT
ESII PLUS 5' LED LIGHT
M
EVAPORATOR FAN
12W 0.30A @ 120VAC
0548144
L1
N
BUNDLE
BROWN
CONDENSING UNIT
COPELAND®
M4FF-0075-CAV-212
R404A
1H28155500
CONDENSING UNIT
RLA= 6.8A
LRA= 33.7.A
MCC= 9.7A
L2
L1
G
SWITCH
SQUARE "D" 55447
125-01-0271
RELAY TYCO
T92P7A22-277
1804241
L2
L1
EVAPORATOR PAN
1500W 6.25A @ ~ 240 VAC
1H95137550
L2
L1
L1
L1
SAFE NET III CONTROLER
PART# 1H59048001
SAFE NET III SENSORS
PART# 0510533 (4m long) black pb1
AIR
PART# 0510532 (4m long) Yellow pb2
COIL
N
L2
G
L2
Black 10G.
Red 10 G.
White 14 G.
Green 10 G.
PROGRAM: 1H59684
TERMINAL BLOCK
125-01-0295
SAFETY
SWITCH
FLOAT SWITCH
M
CONDENSER FAN
15A
15 AMP FUSE
125-01-8604
FUSE HOLDER
125-01-8605
WHT # 14
BLK # 14
RED # 12
BLK # 12
RED # 12
BLK # 12
PRESSURE
SAFETY
225-01-0706B
