CASE MUST BE GROUNDED
NOTE: Refer to label af! xed to case to determine the actual
con! guration as checked in the “TYPE INSTALLED”
boxes.
Electrical Circuit Identi! cation
Standard lighting for all refrigerated models will be full
length LED lamps located within the case at the top.
The switch controlling the lights, the plug provided for
digital scale, and the thermometer are located at the rear
of the case mullion.
The receptacle that is provided on the exterior back
of these models is intended for computerized scales
with a ! ve amp maximum load, not for large motors or
other high wattage appliances. It should be wired to a
dedicated circuit.
Field Wiring and Serial Plate
Amperage
Field Wiring must be sized for component amperes
printed on the serial plate. Actual ampere draw may be
less than speci! ed. Field wiring from the refrigeration
control panel to the merchandisers is required for
refrigeration thermostats. Case amperes are listed on
the wiring diagram, but always check the serial plate.
BEFORE SERVICING
ALWAYS DISCONNECT ELECTRICAL
POWER AT THE MAIN DISCONNECT
WHEN SERVICING OR REPLACING ANY
ELECTRICAL COMPONENT.
This includes (but not limited to) Fans, Heaters
Thermostats, and Lights
DANGER
.
