(To be performed by trained service provider)
Warning! Turn Off case before performing Preventive Maintenance!
Preventive Maintenance Frequency Instructions
Case Interior Quarterly Tub, Coil, Drain, Fan Blades, Motors, Brackets:
Disconnect power from the case before cleaning the Tub, Coil, Fan,
Motor and Drain Area!
Remove Decking, Sub-Deck and Fan Shroud.
Use vacuum to clean Evaporator Coils.
Clean Tub, Coil and Drain with warm water, clean cloth, brush and mild
soap solution.
Remove any debris that may clog drain.
Clean Fan Blades, Motors and Brackets by wiping down with moist
cloth.
Preventive Maintenance (Cont'd)
14. Electrical Wiring Diagrams Index
MODEL DESCRIPTION SIZE DIAGRAM #
IM-03-S IM-03-E5-S 5' 3011858
IM-04-S IM-04-I3-S 3' 1H66325
IM-04-I4-S 4' 1H66352
IM-04-I5-S 5' 1H66328
IM-04-I6-S W/DAN FOSS AK-
CC-210
6' 3004408
IM-04-I8-S W/DAN FOSS AK-
CC-210
8' 3004410
IM-05-S IM-05-I3-S 3' 1H66327
IM-05-I4-S LED LIGHTS 4' 1H61306
IM-05-I5-S 5' 1H66363
IM-05-I5-S (With 30 Amp
cord)
5' 1H76815
IM-05-I6-S 6' 1H66365
IM-05-I8-S 8' 1H66367
IM-05-I8-S W/50 AMP
PLUG
8' 1H80986
IM-04-H IM-04-C6-FH 5-WELL W/
HATCO 66"
6' W6600201
IM-05-E5-FS 2-SOUP W/
LED
5' W6600205
IM-04-S IM-04-I4-FNC-S R-134A 4' 3008650
IM-03-H IM-03-I3-H 208V/240V 3' W6600037
IM-03-4-H 208V 4' W6600014
