Hussmann ISLA Series - Page 30

30
HUSSMANN_GDF_1.1 SHEET SIZE D
MATERIAL - N/A
THIRD
ANGLE
PROJECTION
UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES.
DRAWN BY -CRAIG BOOREY
APPROVED BY - CRAIG BOOREY
TOLERANCES ARE:
DECIMALS .XX
u.03, .XXX u.010
ANGLES
u 2v
DATE DRAWN - 4-18-16
ECN-CAP-0001113
REVIEWED BY -CRAIG BOOREY
REF -
3004410
DIAGRAM-IM-04-I8-S
AK-CC-210 CTLR
REV ECN DATE REVISION DESCRIPTION REV BY CHKD BY APPR BY
A ECN-CAP-0001113 2016/04/18 RELEASED TO PRODUCTION CB CB CB
REVISION HISTORY
NOTES:
CASE MUST BE GROUNDED
WHEN PASSING WIRES THROUGH METAL HOLES A GROMMET MUST BE USED
A
SHEET 1 OF 1
CIRCUIT #1
L1
L2
LOADING
17.6
16.3
20.3
18.8
208V 240V
BUNDLE
ORANGE
M
EVAPORATOR FAN
12W 0.30A @ 120VAC (2)
0477655
LIGHT SWITCH
125-01-0307
CONDENSING UNIT
COPELAND®
FFAP-017Z-CFV-072
R404A
1H96225500
CONDENSING UNIT
RLA= 12.6 A
LRA= 55.0A
MCC= 17.2A
G
EVAPORATOR PAN
1500W 6.25A @ ~ 240 VAC
1H95137550
N
L1
N
L1
BUNDLE
BROWN
M
MM
15A
15 AMP FUSE
125-01-8604
FUSE HOLDER
125-01-8605
L2
Black 10 G.
Red 10 G.
White 14 G.
Green 10 G.
LEDDRIVER
RED +
BLUE -
LED DRIVER
RED +
BLUE -
CANOPY
3500K-4' L.E.D. LIGHT 4441591
SHELVES
3500K-4' L.E.D. LIGHT 4441591
3500K-4' L.E.D. LIGHT 4441591
3500K-4' L.E.D. LIGHT 4441591
3500K-4' L.E.D. LIGHT 4441591
3500K-4' L.E.D. LIGHT 4441591
3500K-4' L.E.D. LIGHT 4441591
3500K-4' L.E.D. LIGHT 4441591
LIGHT CIRCUIT
.89A 96W @ 120V
~208 / ~240 VAC - 60 HZ
G
L2
L1
N
TERMINAL
BLOCK
125-01-0295
GREEN # 10
SAFETY
SWITCH
FLOAT SWITCH
BLACK # 14
RED # 14
BUNDLE
BLUE
POWER SWITCH
125-01-0271
L2
L1
RELAY TYCO
T92P722A-277
1804241
L1
L2
PRESSURE
SAFETY
M
CONDENSER
FAN
L1
DANFOSS® CONTROLLER
AK-CC-210 115V # 084B8534
1H56892500
Danfoss® AK-CC 210
DEF.COMP.
120 VAC
SENSOR
DANFOSS®
# 1H90012500
NOTE: WIRES AT
CONTROL
INPUTS/OUTPUTS
14GA MAX
N
L2
L1
WHITE # 14
L2
L1
Wiring Diagrams (Cont'd)
