Huvitz HLM-1 Service Manual

Auto Lensmeter HLM-1
15
2.6. Diopter Setting Variables List
The followings are diopter setting variables list:
If diopter controlling is performed normally, the length of each row (L) decreases row by
row.
WAVEFRONT DATA INFORMATION [ALL DIOPTER]
0 [-25.01]: L=+174.05; 123.48, 122.67: average distance and distance rates between
the four points and -25D
1 [-19.99]: L=+168.52; 119.09, 119.23: average distance and distance rates between
the four points and -20D
…
6 [+0.00]: L=+135.93; 96.11, 96.12 CX:642.71: average distance and distance rates
between the four points and 0D
7 [+2.50]: L=+131.04; 92.71, 92.62 CY:510.36: average distance and distance rates
between the four points and +2.5D
…
12 [+25.00]: L=+73.17; 51.82, 51.66: average distance and distance rates between
the four points and +25.00D
