Huvitz HLM-1 Service Manual

Auto Lensmeter HLM-1
27
No
Component
Removal method
1
PD-RACK-GEAR-SHAFT
- First, remove [9] from Back Bone Assembly and separate
[2] [3].
- Then, remove 4 screws from [6] and take off [6].
- Remvoe 1 screw and separate [1].
- Please see the drawing for disassemble, as needed
- Be careful that there is no scratch and assembly is the
reverse procedure of disassembly.
2
Z_WASHER_4X16
3
O RING(For PD BAR)
4
B4_PD-SHAFT
5
B4_PD-BAR-PLATE-15KV
6
B6_COVER-PD-BAR
7
SCREW (3*10)
8
TAPPING-SCREW2-FH-M2.3L6
9
SEMS SCREW (3*8)
10
B4_PD-BAR-BACK-COVER
11
MACHINE SCREW(FH)
12
M2_PACHY-REAR-STICKER
