Hycontrol REFLEX User Manual

Ref: REFLEX/SCANFLEX MANUAL
EDITION 1: JULY ’97 13
10. In the 'run' mode three different display layouts are available.
10a. Normal 'RUN' Mode
Point number will be 1 in single point, Reflex mode
and will change continuously between 01 and the max.
number of points in multi point Scanflex mode
4 Boxes show external relay status
in Multipoint mode only. (Dark if
energised)
4 digit display
of level
Bar graph - length proportional to level display
or "Loss of Echo" if this condition exists.
POINT
01
21.39
10b. Display of Secondary Functions
When "TEST" is pressed the display shows gain, distance and loss of echo status for that
point. When "DSP" is pressed it shows mA Output and Temperature for that point.
Press "DSP" Press "TEST" Press CE to return to RUN
Shown only when condition
exists for the point.
POINT : 01
ANALOGUE = 15MA
TEMPERATURE = 20 DEGC
POINT : 01
DISTANCE = 1.7
GAIN = 0.2%
LOSS OF ECHO
Secondary display is of the next scanned
point, not the point in the normal run displa
y
10c. Status check for Scanflex Modules
This is available only if the instrument is configured as a multipoint system and a Multiplexor
and other modules are being used.
When "#" is pressed in RUN mode the display of a Scanflex will show the status and the
number of modules connected to the Controller as defined by Pr.51.
If a box is filled in it indicates a fault in communication. Consult Page 44
If the above displays do not appear then re-set to factory defaults as instructed on Page 16 and
check the entry at Pr.51
11. On Scanflex application also check that the green comms light on the Multiplexor is
flashing and the red status light is scanning from point 1 to point 10 or however many
points are selected.
THE SYSTEM IS NOW READY TO BE PROGRAMMED
UNIT STATUS
Box filled in
shows a fault
